USB Input format support: PCM 16-32bit 44.1Khz 48Khz 88.2Khz 96Khz 176.4Khz 192Khz 352.8Khz
384Khz DSD64, DSD128
Operating system support: Mac OSX, Linux, KS/Wasapi/WDM/ASIO Drivers for MS Windows from XP to Win8 32-
64bit.
Inputs: Optical, Coaxial, AES/EBU: 16-24Bit, 44.1-192KHZ
SNR: -125dB.
Dynamic Range: >122dB.
THD+N: 0.0005% (This is our test equipment's lowest resolution)
Frequency Response: 20-30KHz-0.2dB
Crosstalk -130dB
Full Balanced Output level: 4.2V
Headphone amplifier output power: 600Ù 70mw 300Ù 150mw 150Ù 280mw 32Ù 1W
Power consumption: <30W.
Size: 250*180*45mm.
Net Weight: 1.6Kg
Technical Specifications
15
* Before using D200, it's better to warm up for at least 15 minutes. Please make sure to allow the air to circulate and to use the
headphone with class A to amplify, it is normal that there is a little warm on the surface of D200.
* Please use high quality USB cable. Don't connect D200 via a USB hub, or extension cable (for example most USB ports in
the front of tower case).
* The AC power supply need to be properly grounded, otherwise it is not safe to use, at the same time the noise produced by
the the other electrical equipments will be passed to D200 from power cord, it is also possible that the loop noise will be
produced among the grounding wire, PC, USB and D200.
Suggestion
D200 210*140mm P15
