XP8600/XP8900 Table of Contents s iii
TABLE OF CONTENTS
About This Manual vii
XP8600
Chapter 1: Overview 13
Chapter 2: Getting Started 15
XP8600 Components ........................................................................... 16
Connecting Expansion Boards to a Z-World Controller ......................17
Setting Expansion Board Addresses .................................................... 18
Power ................................................................................................... 19
Chapter 3: I/O Configurations 21
XP8600 Pin Assignments..................................................................... 22
Voltage or Current Output ............................................................... 22
XP8600 Circuitry ................................................................................. 23
The AD7543 Chip ........................................................................... 24
Voltage Output ..............................................................................24
Current Output ..............................................................................25
Reset and Power-Up Delay ........................................................... 25
Chapter 4: Software Reference 27
Expansion Board Addresses ................................................................28
XP8600 ...........................................................................................28
Logical Addresses ......................................................................... 28
LED ..............................................................................................28
XP8600 Software ................................................................................. 29
Dynamic C Libraries .......................................................................29
Using Digital-to-Analog Converter Boards .................................... 30
Reset Boards on PLCBus .............................................................30
Address Target Board ...................................................................31
Operate Target Board....................................................................31
Sample Program ..............................................................................31
