XP8600/XP8900
80 s Specifications
XP8600 Hardware Specifications
Table B-1 summarizes the specifications for the XP8600 expansion board.
The XP8600s voltage regulator, the LM340T-15 at U9, provides 15 V up
to 1 A. The voltage regulators at U8 and U2 provide V-, a regulated -5 V
up to 50 mA. U13, and LT1021 provides a precision 10 V reference
(REF-). The LT1021 is replaced with an LT1019 to provide a precision
2.5 V reference for REF- with 12 V controllers.
Table B-1. XP8600 Specifications
Board Size
2.835" × 3.525" × 0.75"
(72 mm × 90 mm × 19 mm)
Operating Temperature Range -40°C to +70°C
Humidity 5% to 95%, noncondensing
Power (quiescent, no output) 24 V DC, 30 mA
Outputs 2 D/A channels
• voltage output 0 V to 10 V each OR
• current output 0 mA to 22 mA each
