9
The control panel
1. On/Off indicator light
2. On/Off push button
3. Door handle
4. Programme sequence indicator
As the programme progresses, the programme
selector dial turns, to show the phase in the wash
programme the appliance has reached.
Prewash / Rinse and Hold
Wash
Cold rinse
Hot rinse
Drying
5. Programme guide
6. Programme marker
7. Programme selector dial
E
N
D
Description of the appliance
1. Water hardness adjustment
2. Upper basket stop
3. Salt container
4. Detergent dispenser
5. Rinse aid dispenser
6. Control panel
7. Filters
8. Lower spray arm
9. Upper spray arm
10. Upper basket
11. Levelling spacers
12. Worktop
IN101
1
2
3
4
5
6
7
8
9
10
11
12
