Zap Series 3 User Manual

Series 3 Technician’s Installation and Service Training Manual
Table of Contents
Series 3 Technician’s Installation and Service Training Manual Notes
ZAP Controls
100 Waterloo Blvd. Anglesey Business Park, Littleworth Road, Cannock, Staffordshire, England
UK Contact 011-44-154-387-9444 sales@zap-uk.com
USA Contact 931-510-4432 sales@zap-america.com
USA Tech Support 931-510-4432 via telephone or text
Online www.zap-uk.com
872 Adapter Module Installation 53
Photo Cell Installation for Constant Pressure Close / Photo Cell to Stop Upon Obstruction 54
Dock Light Wiring 55
Auto-Close Timer Programming 56
Auto-Close Timer Temporary Defeat 57
Delay Close Programming 58
Part Open Programming 59
Close Slow/ Close Fast Programming 60
Service Due Reminder 61
Operations Counter 62
Basic Troubleshooting Symptom Diagnosis 63-64
Basic Troubleshooting Commercial Operator (Motor Head) 65
Basic Troubleshooting Commercial Operator (Controller) 66
Advanced Troubleshooting Commercial Operator (Controller) 67-69
Adjusting Potentiometers 70
Performing a Master Reset 71
Performing a Factory Reset 72
24V Troubleshooting 73
Single Contact Control Device Trouble Shooting 74
Additional 3 Button Station Control Device Trouble Shooting 75
ZAP Motor Assembly Service (Belt and Bearing Replacement) 76
ZAP Motor Assembly Service (Bowden Cable Replacement) 77
ZAP Motor Assembly Service (Motor Replacement) 78

Zap Series 3 Specifications

General

Type	Chain Drive
Horsepower	1/2 HP
Battery Backup	No
Voltage	120V
Security	Rolling Code
Warranty	1 Year
