3
Thank you for purchasing the Z600C2-SL.
The Z600C2-SL is a no compromise stereo amplifier
conservatively rated at 150 watts per channel into four
ohms, 325 watts per channel into 2 ohms, and 400 watts per
channel into a one ohm load.
The fully regulated power supply in the Z600C2-SL is a new
design that dramatically increases power and efficiency.
New Gate Drive Boost circuitry greatly improves the
MOSFET switching performance and allows for cooler
operation. The Z600 C2-SL is the perfectionist’s no
compromise amplifier as evidenced by such features as its
four layer PC board, and twenty four power devices.
Z600C2-SL Key Features
• Balanced SymbiLink™ Technology • Very high damping factor
• Dual pro audio balanced
differential Inputs
• Triple path global feedback
• Four layer PC board • Massive power / ground planes on all
four layers
• Ultra Low Distortion • Can drive highly reactive loads
• Symmetrical, discrete power
amplifier circuitry
• Massive regulated switching supply
with internal energy storage
• Separate LED's for Power and
Protection
• Short circuit, high temperature,
reverse, DC offset, and over-voltage
protection
• Stable to one ohm • Sixteen 25-ampere bipolar amplifier
output transistors
• Very high current output stage -
Greater that 200 amps / channel
• Quality ZAPCO construction / Made in
the U.S.A.
• Precision 1% resistors used
throughout
• Three year warranty
(Dealer installed)
• Surface mount technology • Eight 50-ampere MOSFET switching
devices
• Low radiated noise for clean AM /
FM reception
• Designed and manufactured in the
USA
