ZAPTEC Go Quick Guide

7
Configure charging station
Scan the QR code with camera and complete the installation
in the Zaptec App.
6
It is possible to configure the charging station without using the
app, please note there might be limited functionality doing so.
Switch is located above the connection terminal.
Switch configurations:
1 - 6 Amps
2 - 10 Amps
3 - 13 Amps
4 - 16 Amps
5 - 20 Amps
6 - 25 Amps
7 - 32 Amps
8 - Not in use
9 - Not in use
0 - Unconfigured or
configured with App

ZAPTEC Go Specifications

General

Type	Electric Vehicle Charger
Charging Power	22 kW
Weight	1.3 kg
Protection Rating	IP54
Charging Standard	IEC 61851-1
Maximum Charging Power	22 kW
Protection Class	Class I
Current Output	32A
Connectivity	Wi-Fi, Bluetooth
Operating Temperature	-30°C to +40°C
Input Voltage	230/400V AC
Cable Length	Not included
