Zebra CR8178-SC - Bottom View Cradle Components

4 CR8178-SC Standard Cradle
Bottom
NOTE When mounting on a mobile cart the desk/wall mount
converter knob must be in the wall mount position (locked).
Keyhole Mounting Hole
Rubber Foot
Rubber Foot
Interface Cable
Groove
Interface Cable
Groove
Interface Cable
Support Hook
Keyhole Mounting Hole
Interface Port
Desk/Wall Mount Converter Knob
Rubber Foot
Rubber Foot
Vertical Mount Threaded
Brass Screw Holes (2 -
M4x5 mm)
Wall or Mobile Cart
Desk
Point Triangle Indicator
Appropriately to Select
