MC93XX Quick Start Guide
21
USB Charge/Com Snap-on Cup
The USB Charge/Com Snap-on Cup:
• Provides 5 VDC power to operate the device and to charge the battery.
• Provides power and/or communication with the host computer over USB to the device.
• Compatible with devices using the following battery:
• 7000 mAh PowerPrecision+ standard battery
Figure 21 USB Charge/Com Snap-on Cup
USB Charge/Com Snap-on Cup
Pigtail with USB Socket
