Zebra TC55 - Capturing Bar Code Data with Imager; Capturing Bar Code Data with Camera

3. Place the red aiming pattern across the bar code or the aiming dot on the bar
code. The LED lights green and a beep sounds, by default, to indicate the bar
code was decoded successfully.
4. The captured data appears in the text field.
To capture bar code data using the camera:
1. Open an application and ensure that a text field is in-focus.
2. Press and hold the programmable button. A preview window appears and the
LED lights red to indicate that data capture is in process.
3. Move the TC55 until the bar code is centered under the red target.
4. The LED lights green and a beep sounds, by default, to indicate the bar code
was decoded successfully.
5. The captured data appears in the text field.
Programmable ButtonProgrammable Button Programmable Button
Programmable Button
