24
* Indicates parts not previously used
PART
NO. DESCRIPTION
PRICE
PART
NO.
DESCRIPTION
PRICE
CHASSIS 6YT01 (Cont ’ d.)
86-464
Connector Terminal - Green Wire 8s Yellow
*86-480
Wire (4 required)
Connector Terminal - Blue Wire (2 req ’ d)
83-6208
Single Lug Terminal Strip
90-743 Spacer Sleeve (1 Used On Ea. 94-1171)
*83-6342
Alignment Strip
94-1171
Insulating Bushing (2 required)
.10
*83-6343
Dial Background Strip
94-1381 Insulating Bushing (4 required)
Position Bandswitch
*95-2565
Output Transformer
86-334 Socket Terminal (3 required)
.10
*95-2566
Output Transformer
86-370
Socket Terminal (5 required)
.03
112-1717
6-32 x 3/8 Phillies Pan Hd. Mach. Screw
86-441
Insulator Feed-Thru Terminal (3 req ’ d)
.05
Cadmium (2 Join Ea. 12-4775 & 800-203)
94-613
113-10
Iron Core Bushing (2 required)
6-32x3/16x1/4 Hex Hd. Mach. Screw-
N.P. - Internal Lockwasher Att.
(2 Mt. 22-4843 & 2 join 12-4758 &
.10
• 114-802
8-18 x 5/16 Hex Washer Hd. Self-Tap.
Screw-Stat. Bronze (3 Join ea. 57-6519
& Chassis .03
Chassis)
.03
114-862
8-18 x 1/2 Hex Washer Hd. Self-Tap. Screw
114-344
6-20x1/4x1/4 Hex Hd. Self-Tap. Screw
- Stat Bronze (2 Used On 12-4775)
.03
Stat. Bronze (2 used on S-77014)
.03
121-430 Transistor • Driver (2 required)
1.10
121-433
Transistor - Pre-Driver (2 required)
1.30
114-809
125-26
*126-1297
8-18 x 3/16 x 1/4 Hex Hd. Self-Tap.
Screw-Stat. Bronze (2 used on ea.
83-6342 & 83-6343 & 2 join ea.
22-4843 & Chassis & 17-143 &
Chassis)
Rubber Grommet
Tuner Shield
.03
.03
125-96
205-51
212-71
800-203
*S-77368
Strain Relief Grommet (Used On 11-183)
Silicone Grease (Part Of 800-203)
Silicon Rectifier
Output Transister Assembly (2 req ’ d)
(121-436)
Phono Input Cable Assembly
.10
.16
1.25
5.25
149-368 Iron Core & Spring
.30
149-385
Iron Core & Spring
.30
CHASSIS 6YT24
188-232
Clamping Ring (2 required)
.03
22-2939
680 Pf Disc Capacitor - 500V. (2 req ’ d) .25
S-57222
Pointer Support Strip & Ring Assembly
.15
22-3878
2000 Mf Electrolytic Capacitor - 75V.
7.10
(2 required)
22-3881
1500 Mf Electrolytic Capacitor » 50V.
5.00
*S-77231
Chassis Mounting Bracket - R.H.
22-4367
. 1 Mf Capacitor • 200V.
*S-77235
Chassis Mounting Bracket - L.H.
22-4369
. lMf Capacitor - 400V.
.40
*S-77264
Drive Cord & Eyelet Assembly (Pointer)
22-4601
.01 Mf Disc Capacitor - 1KV.
.20
*S-77265
Drive Cord & Eyelet Assembly (Pointer)
22-4666 .001 Mf Disc Capacitor - 1KV.
.40
*S-77266
Drive Cord & Eyelet Assembly (Gang)
22-4673
500 Mf Electrolytic Capacitor - 50V.
(2 required)
3.45
CHASSIS 6YT21
22-5162
Three Section Electrolytic Capacitor -
11-183
A. C. Line Cord
.80
22-5262
50V k /50V./25V.
100 Mf Electrolytic Capacitor • 50V.
6.00
1.45
*12-4775
Heat Sink Bracket (2 required)
*22-5455
50 Mf Electrolytic Capacitor - 50V.
22-24
2 x .0047 Mf Disc Capacitor - 500V.
.40
43-333
Three Contact Housing (Male)
.20
22-2793
.047 Mf Capacitor - 400V. (2 required)
43*573
Six Contact Housing (Female)
.45
22-3298
470 Pf Capacitor - 500V. (2 required)
.25
43-574
Nine Contact Housing (Female)
.35
22-3415 .0068 Mf Capacitor - 25V. (2 required)
.25
54-579
10-32 x 3/8 x 3/16 Thick - Hex Nut -
22-3527
.22 Mf Capacitor - 12V. (2 required)
.60
Cadmium (1 Used On Ea. 212-62)
.03
22-3615 1 Mf Electrolytic Capacitor - 25V. (4
62-30
Fuse Holder
.40
required) 1.55
63-1747
120 Ohm Resistor • 1/2W. 10%
. 17
22-4346 .047 Mf Capacitor - 400V.
63-1757
220 Ohm Resistor - 1/2W. 10%
.17
*22-4853 Dual Electrolytic Capacitor - 150V./25V.
63-1761
270 Ohm Resistor - 1/2W. 10%
. 17
22-5251
. 15 Mf Disc Capacitor - 12V. (2 required)
.45
63-1810
3900 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
43-519
Contact Housing (Female) (Used On
.20
63-1820
6800 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
52-1435)
63-1827
10K Ohm Resistor - 1/2 W. 10% (2 req ’ d)
*52-1435
Four Conductor Cable - 7-1/2 ” (Used On
63-1912
1 Megohm Resistor - 1/2W. 20%
.17
54-778
43-519)
63-5217
2 Ohm Resistor - 10W. 10%
.80
6-32 Palnut (4 Used On 112-1717)
63-5282
.39 Ohm Resistor - 5W. 5% (2 required)
.75
*57-6519 Chassis End Plate
63-5367
0.43 Ohm Resistor - 5W. 5% (2 required)
.75
63-1722 33 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
63-5369
220 Ohm Resistor - 5W. 10%
.75
63-1736 68 Ohm Resistor • 1/2W. 10% (2 req ’ d)
.17
63-5638
180 Ohm Resistor - 2W. 10% (2 required)
.34
63-1757
220 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
63-5641
220 Ohm Resistor • 2W. 20% (2 required)
.34
63-1782
820 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
63-5663
680 Ohm Resistor - 2W. 10% (2 required)
.30
63-1817 5600 Ohm Resistor - 1/2 W. 10% (2 req ’ d)
.17
63-5961
2.7 Ohm Resistor - 1W. 10% (4 required)
.25
63-1820 6800 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
63-6442
560 Ohm Resistor - 3W. 10% (2 required)
.30
63-1824
8200 Ohm Resistor - 1/2W. 10% (2 req ’ d)
.17
*63-7311
160 Ohm Resistor - 5W. 10%
63-1827 10K Ohm Resistor - 1/2 W. 10% (2 req ’ d)
.17
78-402
Four Contact Housing
63-1834 15K Ohm Resistor - 1/2W. 10%
.17
78-1347
Electrolytic Socket (3 required)
.10
63-1869
100K Ohm Resistor - 1/2 W. 10% (2 req ’ d)
.17
78-1486
Two Contact Transistor Socket (6 req ’ d)
.35
63-1890 330K Ohm Resistor - 1/2W. 10% (2 req ’ d)
83-3881
Four Lug Terminal Strip
.20
63-1932 3.3 Megohm Resistor - 1/2W. 10% (2 req ’ d)
.17
83-4203
Three Lug Terminal Strip
.05
63-6461
200 Ohm Fusing Type Resistor .55
83-4633
Felt Strip
.03
*63-7336 Dual Tone Control
83-5277
Insulating Strip - Transistor (6 required)
.03
*63-7337 Balance Control
83-5284
Five Lug Terminal Strip (6 required)
.15
*63-7338
Dual Loudness Control
.05
83-5291
Insulating Strip (Used On 83-5284) (6
79-174-37
#18 Sleeving -^Yellow - 4-5/8 ”
required)
.03
*83*6360 Eighteen Lug Terminal Strip
86-303
Terminal • Male (3 required)
.04
*83-6361 Terminal Strip
86-328
Wire Retaining Terminal (2 required)
.03
86-329
Connector Terminal (4 required - Used On
.03
86-389
Terminal - Female (15 required)
.03
Speaker Leads)
93-369
Internal Lockwasher - Shakeproof #1210
86-334
Socket Terminal (4 Used On 52-1435)
.10
(1 Used On Ea. 212-62)
.03
