38
Monsoon I Use, Care, and Installation Guide
MONSOON I
INSERT
CORE
Wiring Diagram
AK9246BS CIRCUIT DIAGRAM
WHITE
RED
YELLOW
GREY
BROWN
BLUE
GREEN
BODY
WHITE
BLUE
BROWN
GREY
RED
YELLOW
GREEN
BODY
MOTOR
MOTOR
YELLOW
YELLOW
RED
YELLOW
YELLOW
RED
YELLOW
YELLOW
YELLOW
YELLOW
OPTIONAL DUAL FAN
BODY
GREEN
BLACK
WHITE
TRANSFORMER
GREY
BROWN
BLUE
WHITE
B/W
ACT 590 CFM - Fan Max. 556W @ 4.6A
ACT 390 CFM - Fan Max. 381W @ 3.4A

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zephyr AK9246BS and is the answer not in the manual?

Zephyr AK9246BS Specifications

General IconGeneral
Colorstainless steel
Hood Typeinsert
Venting Typeducted, external
Temperature Sensorno
Control Typebutton
Delay Startyes
Interior Lightyes
Remote Controlno
Voltage120 volts
Weight and Dimensions IconWeight and Dimensions
Depth19 1/4 inches
Height12 inches
Width46 3/8 inches
Net Weight64.5 pounds
