Free (floating) positio
Speed of three-point linkage lowering control
Hydraulic sensitivity system control
Free (floating) position enables work with a tool which has
supporting wheel. The arms of rear three-point linkage are
free in this position. Shift lever (2) to front position (a).
Position of lever (1) is not decisive.
NM13N011
Speed of three-point linkage lowering control (3) serves
for setting the speed of lowering three-point linkage arms.
When turning the control of speed of three-point linkage
lowering in (b) direction the speed of three-point linkage
arms lowering decreases, in (a) direction it increases. If
we turn speed of lowering control (b) to stop, the arms of
three-point linkage cannot be lowered.
NM13N012
Hydraulic sensitivity system control (4) serves for setting
hydraulic system sensitivity with power or mixed
regulation. When turning the control in the direction (a),
the sensitivity of the system increases, in (b) direction it
decreases.
NM13N013
