2. ZIR32 connection

Open the screw cover and connect the 4-wire cable as below

Wire color ZIR32 connector pin

Red 1 (Power Out)

Black 2 (Ground)

Yellow 3 (ZIR32 Trigger in+)

Green 4 (ZIR32 Trigger in-)
