ZF AV 133 - Page 64

17. Pull bearing outer ring (1) with
5870.300.035 [Extr
acting device] out of the
portal housing.
Fig. 94
18. Loosen cylindrical screw.
Fig. 95
19. Bolt in 5870.204.022 [Locating pin] at the
bear
ing bolt.
20. Force out and remove bearing bolt.
Fig. 96
Dismantling
64
EN 4472.751.001 - 2015-11
