8 Check sensor function
1. Connect the voltage supply (+U
S
/ GND), disconnect output 0 ... 10 V (A / GND).
2. Remove pressure hoses and measure output signal, nominal = 0 V.
3. Create pressure at the "+" connection against the "-" connection (e.g. by carefully
blowing in), measure the output signal (0...10 V
measuring range).
4. If the sensor works, reconnect the pressure hoses and check these if necessary.
Operating Instructions MPG-..V Check sensor function
L-BAL-E248-GB 1931 Index 003 Part.-No. 00163446
8/12
