ZIMO MX618N18 - CV Summary List - Function Mapping and Control

Page 72 Non-Sound Decoder MX618 - MX638 and Sound Decoder MX640 - MX659
Chap-
ter
CV
Denomination
Range
Default
Description
3.6
#66
Forward trimming
0 - 255
0
Multiplication of the speed step by “n/128”
3.6
#67-
94
Free speed table
0 - 255
0
Internal speed step for each of the 28 external steps
3.6
#95
Reverse trimming
0 - 255
0
Multiplication of the speed step by “n/128”
-
#96..
------
-
105,
106
User data
0 - 255
0
Free memory space for user data
3.16
#107
Light suppression
0 - 255
0
Light suppression on cab side 1 (front side)
3.16
#108
Light suppression
0 - 255
0
Light suppression on cab side 2 (rear)
-
#109
Extension of CV 107
1 – 6
0
3. Suppressed output (1 – 6 for FO1 – FO6)
-
#110
Extension of CV 108
1 - 6
0
3. Suppressed output (1 – 6 for FO1 – FO6)
3.1
3.6
3.20
#112
Special ZIMO
configuration bits
0 - 255
4 =
00000100
with Bit 5 = 0
(20 kHz)
Bit 1 = 1: High frequency acknowledgement
Bit 2 = 0/1: ZIMO loco number recognition OFF/ON
Bit 3 = 1: 8-Function Mode (for old ZIMO systems)
Bit 4 = 1: Pulse chain recognition (for old LGB)
Bit 5 = 0/1: motor control frequency in 20/ 40 kHz
Bit 6 = 1: “Märklin” brake (+ CV #29 Bit 2, #124,Bit 5)
Bit 7 = 1: Pulse chain commands
3.6
#113
Compensation
0 - 255
0
Reduced BEMF intensity at speed step in CV #10.
3.19
#114
Dim Mask 1
Bits 0 - 7
0
Exclusion of individ. outputs from dimming per CV #60.
3.24
#115
Uncoupler control
0 - 99
0
With effect 48: Pull-in time (tens), hold volt (ones digit)
3.24
#116
Automatic uncouple
0 - 199
0
Unload (hundredths), drive time (tens), speed (ones)
3.20
#117
Flasher functions
0 - 99
0
Tens digit = ON time / Ones digit = OFF time
3.20
#118
Flashing mask
Bits 0 - 7
0
Selected function outputs will flash as per CV #117
3.19
#119
F6 low beam mask.
Bits 0 - 7
0
Selected outputs will dim with F6 according to CV #60.
3.19
#120
F7 low beam mask
Bits 0 - 7
Selected outputs will dim with F7 according to CV #60.
3.7
#121
Expon. acceleration
0 - 99
0
Tens digit: speed range, Ones digit: curve (0 to 9).
3.7
#122
Expon. deceleration
0 - 99
0
Tens digit: speed range, Ones digit: curve (0 to 9).
3.7
#123
Adaptive accel/decel
0 - 99
0
Tens digit: acceleration, Ones digit: deceleration
3.13
#124
Shunting keys, Out-
puts instead of SUSI
Bits
0 - 4, 6, 7
0
Shunting key (half speed, no momentum), switch SUSI
to function outputs, DC braking.
3.22
#125
#126
#127
#128
#129
#130
Effects F0 front
F0 rear
F1
F2
F3
F4
0 - 255
0
Bits 1, 0 = 00: directional (active in both directions)
= 01: only forward
= 10: only reverse
Bits 7, 6, 5, 4, 3, 2 = Effect-Code, i.e.:
Uncoupler - 00110000 = “48”
Chap-
ter
CV
Denomination
Range
Default
Description
#131
#132
F5
F6
Soft-Start for function output - 00110100 = “52”
Autom. Brake light - 00111000 = „56“
and so on.
3.23
#133
FO4 for exhaust fan
0, 1
0
= 0 : FO4 as normal output = 1: for an exhaust fan.
3.10
#134
Asym. stopping (ABC)
1 - 14,101..
106
Hundreds: Sensitivity, Tens and Ones digit: Threshold
3.8
#135
Km/h - Speed
2 - 20
0
= 1  Initiates a calibration run; 5, 10, 20: km/h step.
3.8
#136
Km/h – Speed
or
RailCom
Control value after calibration; or RailCom correction
3.23
#137
#138
#139
Smoke generator
characteristic
0 - 255
0 - 255
0 - 255
0
0
0
Effect 72 / 80: CV #137: PWM of FOx at standstill
CV #138: PWM of FOx at cruising speed
CV #139: PWM of FOx at acceleration
3.12
#140
Distance controlled
stopping
0-3, 11-13
0
= 1: HLU or ABC, = 2: manual, = 3: man. & auto stops.
3.12
#141
Distance controlled
stopping
0 - 255
0
“Constant distance”, Stop point: 255 = 500 yards
3.12
#142
Distance controlled
stopping
0 - 255
12
High speed correction with ABC
3.12
#143
Distance controlled
stopping
0 - 255
0
High speed correction with HLU
3.1
#144
Programing/Update
Lock
Bits 6, 7
0
Bit 6 = 1: “Service Mode“ lock, Bit 7 = 1: update lock.
3.6
#145
Alternative
motor control
-
0
= 1: Special setting for Fleischmann round motor = 2:.
= 10: “normal” C-Sinus and Softdrive-Sinus
= 11: alternative C-Sinus / Softdrive Sinus
= 12: special C-Sinus and Softdrive-Sinus
=13: special C- / Softdrive-Sinus control mode for the
Märklin “Gottardo” engine
3.7
#146
Gear backlash
0 - 255
0
Hundredths of a second the motor spins at minimum
rpm after direction change
3.6
147..
Experimental CV’s
0 - 255
0
Special settings for motor control
3.6
#151
Motor brake
0 - 9
0
= 1 … 9: Strength and reaction of the motor brake
3.19
#152
Dim Mask 2
Bits 0 - 7
0
Exclusion of individ. outputs from dimming per CV #60
-
#153
Continue w/o signal
0 - 255
0
Stops in tenths of seconds after the last DCC signal.
-
#154
Special OEM-Bits.
For certain sound projects only
3.13
#155
Half-speed key
0 - 19
0
Key for half-speed activation (instead of CV #124)
3.13
#156
Momentum deact.
0 - 19
0
Momentum deactivation key (instead of CV #124)
3.13
#157
MAN key.
0 - 19
0
Selecting a key for the MAN functions
