Page 76 Non-Sound Decoder MX618 - MX638 and Sound Decoder MX640 - MX659
Chap-
ter
CV
Denomination
Range
Default
Description
5.7
#382
Electric brake -
maximum speed
0 – 255
0
No electric brake sound above this speed.
5.7
#383
Electric brake -
Pitch
0 – 255
0
0=Pitch independent of speed,
1-255=increases playback speed
5.7
#384
Electric brake –
Deceleration
threshold
0 – 255
0
The number of speed steps to be reduced during de-
celeration before the electric brake sound is played
back.
5.7
#385
Electric brake –
Downhill
(neg. motor load)
0 - 255
0
= 0: no effect at “negative” load
= 1 – 255: Sound triggered at “negative” load.
5.7
#386
Electric brake –
Loop
0 - 15
0
Bit 3 = 0: Sound fades out at the sample end
= 1: Sound ends without fading at end
Bit 2…0: Increases playback time (0-7=0-7 seconds).
5.7
#387
Acceleration
influence
0 – 255
0
Acceleration influence on diesel sound steps.
5.7
#388
Deceleration
influence
0 – 255
0
Deceleration influence on diesel sound steps.
5.7
#389
Acceleration limit of
diesel sound
0 – 255
0
Limits how far the sound step may deviate during ac-
celeration from the actual speed.
5.7
#390
Momentum reduc-
tion - driving solo
0 – 255
0
Reducing CV #3, CV #4 when “Solo” driving key is en-
gaged.
5.7
#391
Idle sound,
when driving solo
0 – 255
0
Keep sound at idle up to this speed step when driving
“solo”.
#392
-
-
-
-
#393
ZIMO-Config. 5
0 – 255
0
Bit 0 = 1: activate ditch light if bell is played
Bit 1 = 1: activate ditch light if horn is played
3.25
5.5
#394
ZIMO-Config. 4
0 – 255
0
Various bit configurations.
5.4
#395
Maximum volume
0 – 255
0
Max. volume for key defined with CV# 396, /#397
5.4
#396
Volume decrease
key
0 – 29
0
5.4
#397
Volume increase key
0 – 29
0
5.7
#398
Automated coasting
0 – 255
0
The number of speed steps the train’s speed has to be
reduced within 0.5 seconds in order for the automatic
coasting effect to set the motor sound to idle.
3.17
#399
“Rule 17“,Speed de-
pendent headlights
0 – 255
0
Switches to high beam at speed defined here.
SEE CV #430 - !
3.18
#400
-
#428
Input-Mapping
0 – 255
0
Matching function key (External Function) to function
outputs F0 - F28.
Chap-
ter
CV
Denomination
Range
Default
Description
#429
------
-
-
-
3.17
#430
#436
#442
#448
#454
#460
#466
#472
#478
#484
#490
#496
#502
Function-Key
From SW 32.0
“Swiss” light
mapping!
0 – 157
0
Value range: 0,1-29
The key defined here switches the function outputs
listed under A1 and A2 ON or OFF.
1 – 28 for function keys F1 – F28, F29 is for F0.
From SW 35.0:
F-Key value + 128 (Bit 7 set) = Function inverted
3.17
#431
#437
#443
#449
#455
#461
#467
#473
#479
#485
#491
#497
#503
Master light switch
0 – 255
0
0=nothing defined,1-28 for Key F1-F28, 29 for F0
If Bit 7 is set (Value +128):
The F-Key outputs will only turn on when the M-Key is
also on.
If Bit 6 is set (Value +64):
The M-Key outputs will not be turned off when the F-
key is on and driving in forward direction.
If Bit 5 is set (Value +32):
The M-Key outputs will not be turned off when the F-
key is on and driving in reverse direction.
255=High beam function for any F-key – ONLY when
the output in ON and dimmed (via CV #60, CV #114 or
CV #152!
3.17
#432
#438
#444
#450
#456
#462
#468
#474
#480
#486
#492
#498
#504
A1 Forward
0 - 255
0
Value range: 0, 1-13, 14-15
1. Output to be switched on in forward direction.
0=no output, 1-13=FO1-FO13, 14=FO0v, 15=FO0r.
Bit 7-5: Refers to 5 PWM-Config-CVs(508-512).
Configuration 6 (1100xxxx) Output is turned off.
Config. 7 (1110xxxx) Output is turned on.
3.17
#433
#438
#445
#451
#457
#463
A2 Forward
0 – 255
0
Value range: 0, 1-13, 14-15
2. Output to be switched on in forward direction.
0=no output, 1-13=FO1-FO13, 14=FO0v, 15=FO0r.
Bit 7-5: Refers to 5 PWM-Config-CVs(508-512).
