RG-6 cable run, max. 100 ft total
B-Band Converter Module (BBC Module, SUP-2400),
connect to the back of receiver.
B-Band Converter Module (BBC Module, SUP-2400),
connect to the back of receiver.
MPEG4-capable HD receiver
MPEG4-capable HD receiver
(Dish not shown. Appearance of LNB may vary depending on brand.)
110°/119° W.L. Ku LNBs
Ka/Ku LNB (99°/101°/103° W.L. LNB)
Non-MPEG4-capable Receiver
Non-MPEG4-capable Receiver
(Local Channels are 2-digit numbers.)
(Local Channels are 3-digit numbers.)
Connecting with no WB68 (Possible Existing Connection)
If you have an existing Ka/Ku Dish system for HD receivers, but are not presently using a WB68, this diagram shows
what you are likely to have installed currently. Refer to the diagram on page 4 to see how your setup may have to
change.
