Zipro Olympic - Parts List

28
EN
PARTS LIST
No.
Description
Quantity
No.
Description
Quantity
1 Main frame 1 49 Air spring 2
2 Base frame 1 50 Motor cover 1
3 L/R Treadmill column 1/1 51 Lower motor cover 1
4 Motor base 1 52 Grip cap 2
5
Running belt inclination frame
1
53
Anti
-
slip belt
2
6 Computer frame 1 54 L/R Rear trim L/R 1/1
7 L/R
Wheel base
1/1
55 L/R
Front trim L/R
1/1
8 Bolt M6*25 2 56 Computer housing (upper) 1
9
Bolt M8*32
4
57
Computer housing (lower)
1
10 Screw ST4.2*12 13 58 Computer decal 1
11
Bolt M5*15
7
59
Running belt shock absorbers
2
12 Bolt M10*95 1 60 Running belt shock absorbers 2
13 Bolt M10*45 1 61 Rear handling wheel 2
14 Screw ST4.2*25 6 62 Handling wheels 2
15 Screw ST4.2*15 2 63 Legs 6
16 Screw ST4.2*15 ϕ8 10 64 Control 2
17 Bolt M8*35 1 65 Drive belt 1
18 Bolt M8*45 2 66 Handling wheel cover 2
19 SCREW ST4*20 25 67 Grip cap 2
20 Bolt M8*30 1 68 Grip foam 2
21 Bolt M8*25 1 69 Elastomers 4
22
Bolt M8*40
3
70
Running belt
1
23 Internal serrated washer 2 71 Running belt board 1
24
Bolt M10*25
4
72
Supply cable sleeve
1
25 Bolt M8*60 3 73 Anti-slip pads 2
26
Bolt M8*15
4
74
Sensor frame
1
27 Bolt M8*20 8 75 Power cord 1
28 Bolt M8*55 4 76 Handrail buttons 2
29 Bolt M8*48 4 77 On/off button 1
30 Nylon nut M8 8 78 Motor 1
31 Screw ST4*12 4 79 Height adjustment motor 1
32 Nylon nut M10 3 80 Magnetic ring 2
33 Bolt ST3.5*70 4 81 Light sensor 1
34 Flat washer D8 8 82 Sensor frame 1
35 Internal serrated washer D8 23 83 Power cord 16#*130 1
36 Internal serrated washer D10 5 84 Power cord 16#*150 1
37 Spring washer D8 8 85 Power cord 16#*150 1
38 Spring washer D10 4 86 Control panel 1
39
Bolt ST3.0*10
ϕ
6
