ZMODO Pivot - Getting to Know Your Pivot; Pivot Device Components; Door;Window Sensor Components

Door/Window Sensors
Removable Cover
Button for Configuration
Replaceable Battery
①
②
③
1
1
Getting to know your Pivot
Using the Touch Pad:
To reset the Pivot, touch and hold for 10 seconds. To enable Bluetooth
pairing, double-tap rapidly until you hear “Pairing”.
Touch Pad
Status Ring
Temperature
& Humidity Sensor
IR (Infrared) LED
HD Camera
Microphone
Light Sensor
Speaker
Power Port
Speaker
⑩
⑩
①
②
③
④
⑤
⑥
Pivot:
⑤
Plastic Tab - remove to
initiate
Magnetic Portion
Main Portion
④
⑥
