E Series Service Manual

5-4 9650-1450-01 Rev. D

5. Remove the clear plastic spacer from between the cable

connector and upper housing by grasping the center with

needlenose pliers, and pushing straight up.

6. Disconnect the cable from the system board by pulling

straight away from the board.

Note: Place front panel on top of unit to get better access to the spacer and

cable.
