7
Zon 4MT08
4 Configuring the number of shots in a series.
The electronic control-unit MT08 can be configured to operate the gas cannon
and let it produce 1, 2, 3 or 4 shots in a series, with approximately 5 seconds
between each shot. The number of shots in a series is controlled with dipswitch
1 and 2.
Series Dipswitch 1 Dipswitch 2
1 shot Off Off
2 shots On Off
3 shots Off On
4 shots On On
ON
DIP
1 2 3 4 5 6
ON
DIP
1 2 3 4 5 6
ON
DIP
1 2 3 4 5 6
ON
DIP
1 2 3 4 5 6
