Dialer LED Behavior
The dialer's LED can give you useful information about the
dialer and the line it's connected to. Here is a table, which
shows the LED's blinking patterns and what they mean.
LED Pattern Meaning
OFF The dialer is OFF HOOK.
This can be because someone is using a
phone, or because the dialer is receiving a
download. The LED will also be OFF if the
dialer has no power.
Pair Of Rapid Blinks Every
Second:
☼☼ ☼☼ ☼☼ ☼☼ ☼☼
Repeats Continuously
This pattern of two rapid blinks followed by
a short pause indicates that the dialer has
received a download, and that the line is ON
HOOK. The dialer is ready to route a call.
Very Slow Blinking:
☼ ☼ ☼ ☼
Repeats Continuously
This pattern indicates that the dialer is
waiting for a download. In this state, the
dialer will not attempt to route your calls.
ON
☼
When the LED is ON solidly, it indicates that
the phone wires are connected in an 'Inverse'
configuration.
Please plug the phone line
into the dialer's other jack.
Other Blinking Patterns:
☼ ☼☼☼ ☼☼
The dialer will blink in other patterns when
first powered up, while receiving a download,
and while routing calls.
This is normal.
