Zoom Single - Parts and Tools Identification; Tools Required for Assembly; Detailed Parts List

4
Tools
Parts List
4mm Allen Wrench (included)
Phillips Head Screwdriver
and/or Power Drill
Tape Measure
Parts List
Part Qty
Leg 2
Foot 2
Frame End-CB 1
Frame End 1
Centre Rail 1
Part Qty
Side Bracket 2
Control Box 1
Handset 1
Power Cord 1
Cable 1
Part Qty
M6x14 Machine Screw 12
M6x10 Machine Screw 16
M5x20 Wood Screw 11
M5x16 Wood Screw 2
Cable Chip 10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
8
9
7
1
2
4
5
3
12
12
12
12
6
6
11
11
12
13
13
13
11
10
