ZXR10ZSRV2HardwareDescription
Buttons
ThereisonepowerbuttonontheZXR102800-4DCpowersupplymodule.Fora
descriptionofthebutton,refertoT able3-7.
Table3-7PowerButtonDescriptionfortheZXR102800-4DCPowerSupplyModule
ButtonDescription
ON(—)Powersonthepowersupplymodule.
OFF(O)Powersoffthepowersupplymodule.
TechnicalParameters
ForthetechnicalparametersoftheDCpowersupplymoduleoftheZXR102800-4,refer
toTable3-8.
Table3-8TechnicalParametersoftheDCPowerSupplyModuleoftheZXR102800-4
ParameterSpecication
Dimensions(height×width×
depth)
3.15in.×1.57in.×6.89in.(80mm×40mm×175mm)
Weight1.45lb.(0.52kg)
Inputvoltagerange-72VDCto-38VDC
Maximumoutputpower250W
Ratedinputcurrent8.5A
3.3Fan
ThereisaverticalfanmoduleintheZXR102800-4chassis,whichconsistsoftwofans.
Thecoolairentersthechassisfromitslateralside,owstotheboardsandpowersupply
modules,andthenisblownoutfromtheotherside.
Thefanmodulecanautomaticallyadjustthefanspeedaccordingtotheequipment
operationandsupportsthestatusmonitoringandalarmfunctions.
ForthetechnicalspecicationsoftheZXR102800-4fanmodule,refertoTable3-9.
Table3-9ZXR102800-4FanSpecications
ParameterSpecication
Size(W×H×D)40.8mm×81.1mm×186mm
Weight0.44kg
Powerconsumption30W
Maximumwindpressure23mmH
2
O
Maximumwind191CFM
3-6
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
