Chapter7ServiceConguration
CommandFunction
zte(cfg)#showlacpaggregator
[<trunkid>]
Thisdisplays
theaggregation
informationabout
theLACPaggregation
group.
zte(cfg)#showlacpport[<portlist>]Thisdisplaysthe
informationofthe
portwheretheLACP
isinvolvedinthe
aggregation.
LACPConfigurationExample
AsshowninFigure48,switchAandswitchBareconnected
throughtheaggregationport(bindingtheport15andport16).
Port1ofswitchAandport2ofswitchBbelongtoVLAN2.Port3
ofswitchAandport4ofswitchBbelongtoVLAN3.Membersof
thesameVLANcancommunicatewitheachother .
FIGURE48EXAMPLEOFLACPCONFIGURATION
ThedetailedcongurationofswitchAisasfollows:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator3addport15-16
zte(cfg)#setlacpaggregator3modedynamic
zte(cfg)#setvlan2addtrunk3tag
zte(cfg)#setvlan2addport1untag
zte(cfg)#setvlan3addtrunk3tag
zte(cfg)#setvlan3addport3untag
zte(cfg)#setport1pvid2
zte(cfg)#setport3pvid3
zte(cfg)#setvlan2-3enable
ThedetailedcongurationofswitchBisasfollows:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator3addport15-16
zte(cfg)#setlacpaggregator3modedynamic
zte(cfg)#setvlan2addtrunk3tag
zte(cfg)#setvlan2addport2untag
zte(cfg)#setvlan3addtrunk3tag
zte(cfg)#setvlan3addport4untag
zte(cfg)#setport2pvid2
