Zte ZXR10 2900 Series - Figure 70 L2 Pt Configuration Example; Layer 2 Protocol Transparent Transmission Configuration Example

ZXR102900SeriesUserManual
CommandFunction
zte(cfg)#setl2pt<protocol-list>{enable
|disable|invalid}
Thisenablesordisables
L2pttransparent
transmissionfunction.
enableistoenable
layer2transparent
transmission,disable
istodisablelayer
2transparent
transmission,invalid
istomakelayer2
transparentinvalid.All
thelayer2transparent
protocolsareinvalidby
default.
zte(cfg)#showl2ptThisdisplaysthe
congurationof
L2pttransparent
transmission.
Layer2ProtocolTransparent
TransmissionConfigurationExample
AsshowninFigure70,settheLACPtransparenttransmissionfunc-
tionofL2ptofswitch1toimplementthelinkaggregationbetween
switch2andswitch3.Thecongurationincreasesthelinkband-
widthandrealizestheredundantbackup.
FIGURE70L2PTCONFIGURATIONEXAMPLE
Congurationofswitch:
zte(cfg)#setlacpenable
zte(cfg)#setlacpaggregator1addport1，2
