Chapter3ZXR102800-4Chassis
ButtonDescription
OFF(O)Powersoffthepowersupplymodule.
TechnicalParameters
ForthetechnicalparametersoftheACpowerrectieroftheZXR102800-4,refertoTable
3-5.
Table3-5TechnicalParametersoftheACPowerRectieroftheZXR102800-4
ParameterSpecication
Dimensions(height×
width×depth)
3.15in.×1.57in.×6.89in.(80mm×40mm×175mm)
Weight0.68kg
Inputvoltagerange100VACto240VAC
ACinputfrequency50Hzto60Hz
Ratedoutputpower250W
3.2.2DCPowerSupplyModule
Panel
ForthefrontviewoftheDCpowersupplymoduleoftheZXR102800-4,seeFigure3-5.
Figure3-5PaneloftheDCPowerSupplyModule
Indicators
ForadescriptionoftheZXR102800-4DCpowersupplyindicators,refertoTable3-6.
Table3-6IndicatorDescriptionsfortheZXR102800-4DCPowerSupplyModule
IndicatorNumberColorDescription
RUN1GreenIndicatesthatthepowersupplymodule
operatesproperly.
ALM1RedIndicatesthatthepowersupplymodulehas
analarm.
3-5
SJ-20150204153047-004|2015-03-30(R1.0)ZTEProprietaryandCondential
