CommandFunction
showvlanvoice-vlandefault-oui(allcongurationmodes)DisplaysthedefaultOUIofa
device.
showvlanvoice-vlanuser-tableport<port-id>(allconguration
modes)
Displaystheusertableonaport.
showvlanvoice-vlan<vlanlist>qos(allcongurationmodes)DisplaysvoiceVLANQoS
conguration.
VoiceVLANCongurationInstance
lCongurationDescription
SeeFigure5-51,thetwoIPPhonesareinVLAN10andVLAN20,respectively.The
voiceVLANisVLAN100.
Figure5-51VoiceVLANCongurationInstance
lCongurationProcedure
zte(cfg)#setvlan10,20,100addport1-3tag
zte(cfg)#setvlan10,20,100enable
zte(cfg)#setvlanvoice-vlanport1oui-id1mac-addr00.00.01.00.00.01
mac-maskFF.FF.FF.FF.FF.FF
zte(cfg)#setvlanvoice-vlanport2oui-id1mac-addr00.00.01.00.00.02
mac-maskFF.FF.FF.FF.FF.FF
zte(cfg)#setvlanvoice-vlanport1ingress-vlan10voice-vlan100
zte(cfg)#setvlanvoice-vlanport2ingress-vlan20voice-vlan100
lCongurationVerication
zte(cfg)#showvlanvoice-vlan
PortId:1
CustomerVlanList:10
Voice-vlan:100
Ouiconfiged:
oui-id:1mac:00.00.01.00.00.01mask:FF.FF.FF.FF.FF.FF
PortId:2
