ZXR105900ESeriesUserManual(EthernetSwitchingVolume)
St-
ep
CommandFunction
2
ZXR10(config)#showvlansubnet-map
Thisdisplayscongurationof
subnetVLAN.
Example
AsshowninFigure4,congureVLANdataontheswitch.Cong-
ureVLAN20andVLAN30.Portgei_1/1belongstoVLAN20,port
gei_1/2belongstoVLAN30,portgei_1/10belongstobothVLAN20
andVLAN30.ConguredifferentPVIDsforgei_1/1,gei_1/2and
gei_1/10.PCsin20.20.20.0/24haveaccesstoserver1,andthe
PCwhoseIPaddressis30.30.30.1hasaccesstoserver2.
FIGURE4SUBNETVLANCONFIGURATIONEXAMPLE
Congurationofswitch:
/*CreateaVLANandassignportstoit*/
ZXR10(config)#interfacegei_1/1
ZXR10(config-gei_1/1)#switchportmodehybrid
ZXR10(config-gei_1/1)#switchporthybridnativevlan20
ZXR10(config-gei_1/1)#switchporthybridvlan20untag
ZXR10(config-gei_1/1)#exit
ZXR10(config)#interfacegei_1/2
ZXR10(config-gei_1/2)#switchportmodehybrid
ZXR10(config-gei_1/2)#switchporthybridnativevlan30
ZXR10(config-gei_1/2)#switchporthybridvlan30untag
ZXR10(config-gei_1/2)#exit
