Chapter8
ZESRandSVLAN
LinkageNetworking
Configuration
TableofContents
ZESRandSVLANLinkageNetworkingOverview.....................75
ConguringZESRandSVLANLinkageNetworking.................76
CongurationExample.......................................................78
ZESRandSVLANLinkage
NetworkingOverview
ZESRandSVLANlinkagenetworkingisapplicableformulti-ring
multi-domainnetwork.SVLANcanswitchportsquicklyaccording
toring'sconnectivitystatuswhenfaultoccursonthenodeofring.
WhenconguringSVLAN,eachcongurationdataonlycandes-
ignateacustomerportasanuplinkport.Meanwhile,agroup
ofin-vlanandcustomerportonlycancongureaSVLANdata.
Thereforeitisnecessarytocongurevlanattributeofanotherport
sameasthatofuplinkportfordesignatingmultipleuplinkports
forSVLAN.
CongureSVLANandVLANtwodifferentuplinkports,oneisactive
andanotherisstandby.Butonlyoneportcanbeactiveatone
time,maintainonlyonelogicallyconnectiveroutebetweenany
twonodescontrolledbyZESRconguration.
