FrontPanelFrontpanelisshowninFigure61.
FIGURE61FRONTPANELOFRS-89H2-48GE-SFPCARD
InterfacesOpticalmoduleusedbyRS-89H2-48GE-SFPinterfaceishot-swap
SFPopticalmodule.Eachportsupportsdifferenttransmissiondis-
tancesusedbygigabitEthernet.CharacteristicsareshowninTable
108.
TABLE108INTERFACECHARACTERISTICSOFRS-89H2-48GE-SFPCARD
InterfaceType
Characteristics
1000BASE-SX
SFP-M500
LCconnector ,multi-modeber ,wavelength:
850nm,max.transmissiondistance:500m
Transmissionpowerrange:-9.5Bm~-4
dBm;receivingsensitivity:≥-18dBm
1000BASE-LXSFP-S10K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
10km
Transmissionpowerrange:-9.5Bm~-3
dBm;receivingsensitivity:≥-20dBm
1000BASE-LXSFP-S40K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:
40km
Transmittingpowerrange:-4dBm~0dBm;
receivingsensitivity:≥-22dBm
1000BASE-LHSFP-S80K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
80km
Transmittingpowerrange:0dBm~5dBm;
receivingsensitivity:≥-22dBm
1000BASE-LH
SFP-S120K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
120km
Transmittingpowerrange:5dBm~9dBm,
receivingsensitivity:≥-30dBm
LEDTypeThereare48LEDsonthefrontpanelofRS-89H2-48GE-SFPcard.
EachinterfacecorrespondstooneLED.FunctionsoftheseLEDs
aredescribedinTable109.
