ZWO ASI2600 Series - Camera Technical Specifications

ASI2600 Manual
5
3. Camera technical specifications
Sensor
SONY IMX571 CMOS
Diagonal
28.3mm
Resolution
26 Mega Pixels
6248*4176
Pixel Size
3.76μm
Image area
23.5*17.5mm
Max FPS at full resolution
3.51FPS
Shutter
Rolling shutter
Exposure Range
32μs-2000s
Read Noise
1.0-3.3e
QE peak
Above 80% (OSC)
Around 91%(mono)
Full well
50ke
ADC
16bit
DDR3 buffer
256MB
Interface
USB3.0/USB2.0
Adapters
M42*0.75
Protect window
AR window (mono)
IR CUT (OSC)
Dimensions
90mm
Weight
0.7kg
Back Focus Distance
17.5mm
Cooling:
Regulated Two Stage TEC
Delta T
35°C below ambient
Cooling Power consumption
12V at 3A Max
Supported OS
Windows, Linux & Mac OSX
