CAMERA CABLES
Camera Cables (available in lengths of 15, 35 or 50 feet) use the STP (shielded twisted pair) cable standard. The
camera cables are connected using molded 2x3 Molex interfaces that are keyed to prevent improper mating. Each
connector uses a clip to snap securely to each camera and to the inputs on your DVR. Typical configurations are
such that the passenger cameras connect to inputs 1 and 2; and, if available, door, exterior, or driver cameras
connect to inputs 3 and 4. After the installation, all Camera Cables should be concealed and holes filled with
grommets to protect the equipment from vandalism.
EVENT MARKER
The Event Marker is used for the driver to indicate a critical event during recording, which the DVR will interpret as a
priority video for later review. When the driver presses the event marker button, the DVR will mark all video feeds
from 150 seconds (user configurable) prior to and after the button press. These priority event videos can be
retrieved by the technician, using our USB memory stick, to be viewed on a computer with the DVRViewer
application installed, removing the storage media and bringing inside for review or in conjunction with our
Touchdown WIFI system for automatic upload of the video event. The Event Marker module has one button, to
signal an event, and 3 color lights to indicate three DVR states: green for
POWER; amber for RECORDING; and red
for
VIDEO LOST when a camera signal has been lost.
POWER CABLE
A three-wire, 12-feet-long Power Cable is used for connecting the DVR directly to the battery power in the vehicle’s
electrical box. The cable uses a large molded 2x2 Molex connector that is keyed, thereby connecting to the DVR in
only one orientation. The cable’s three wires are described in the following table:
Constant LIVE Power Source
(battery side of solenoid, direct current)
in bus electrical panel
(live only if ignition is turned to ON/ ACC)
Two screws (#4 thread, 3/8“ long) are included to securely fasten the Power Cable to the DVR. Securing the Power
Cable to the DVR prevents occupants from deactivating the system by disconnecting the Power Cable
. NOTE:
MAKE SURE TO FUSE BOTH THE RED AND WHITE POWER LINES WITH A 7.5A FUSE (NOT
INCLUDED)
SENSOR & ALARM CABLE (DIGITAL I/O)
The Digital I/O Cable is used for connecting the DVR to the vehicle’s pertinent electrical functions, such as the turn
signals, brake lights, and the stop-arm. The cable is 15 feet long and connects to the DVR using a molded 2x5 Molex
connector, and to the vehicle’s equipment using 4 twisted pairs of wires. Using the Digital I/O Cable is an optional
function at your discretion.
TEXT OVERLAY – LEFT SIGNAL
TEXT OVERLAY – RIGHT SIGNAL
