DIP Switches
When the battery module is used in parallel, you can use the DIP switch to set the
address to distinguish different battery modules. Default setting for this power station is
Address #1. The DIP switch definition is shown in the table below.
Attention! Avoid setting the same addresses for different battery modules.
This may cause the system to crash.
Address
DIP switch position
Operating mode
1 2 3 4
0 OFF OFF OFF OFF Single mode
1 ON OFF OFF OFF Master (host)
2 OFF ON OFF OFF Slave 2
3 ON ON OFF OFF Slave 3
4 OFF OFF ON OFF Slave 4
5 ON OFF ON OFF Slave 5
6 OFF ON ON OFF Slave 6
7 ON ON ON OFF Slave 7
8 OFF OFF OFF OFF Slave 8
9 ON OFF OFF ON Slave 9
10 OFF ON OFF ON Slave 10
11 ON ON OFF ON Slave 11
12 OFF OFF ON ON Slave 12
13 ON OFF ON ON Slave 13
14 OFF ON ON ON Slave 14
15 ON ON ON ON Slave 15
