2x4basics 90164MI - User Manual of Product 1

A = X x Y x ½” 1.0” thick
= X x Y x 13mm 25mm thick
= Sheeting Material
B,C,D = 2x4’s x
= 1.5” x 3.5” x
= 38mm x 89mm x
* This diagonally placed 2x4 helps support the worktop. It is best cut to fit, but the length can be calculated as:
(√ ((length – 3”) ² + (width – 3”) ²)) – 1.25”
x4
x52
#10 x 3”
Deck Screw
