2xWireless 2X - Assembly of the radio unit and reflector

Assembly of the radio unit and reflector
3. Insert the feed horn of the radio unit through the hole of the reflector plate as shown.
Orientation is not important at this time.
4. Attach the reflector to the radio unit with (4) 10-24 Phillips machine screws. Tighten the screws
¼ turn past snug.
