3 Legged thing Legends Mike User Manual

Quick Release Plate Clamp Knob
Camera Screw
Casing
Pan Lock
Pan Arm Attachment
Point (one on each side)
Pan Base
Tilt Lock
1 2
3
4
5
6
7
8
ANATOMY OF AN AIRHED CINE
The clamp has an orange locking knob (2) for
releasing the Plate.
NEVER undo any of the knobs without holding your
camera.
IMPORTANT
The Release Plate included in the 3 Legged Thing
Legends Tripod Kits has security bolts tted. These
t into the cut-outs engineered in the AirHed Cine
and are intended to give you an additional level of
security.
It is important that you tighten your release plate onto
the clamp completely and check, before use.
Your release plate may come with additional
mounting screws you might not require. Unscrew
these and put them somewhere for safekeeping.
The panning arm can be attached on the left or the
right for either left or right-handed users. Simply rotate
the screw head to ensure the handle is in the desired
position and screw it into the panning arm threads
located on the left or right side of the AirHed (a).
The AirHed Base features a ratchet function in the
pan lock (7 above) which enables you to reposition
the locking knob if it cannot turn due to its position.
To adjust the position, pull the ratchet away from the
base of the AirHed, turn it until it has space to move,
then click it into place. Then you can turn it to loosen
or tighten the lock as required.
AirHeds and Release Plates
Bubble Levels
9 10
Pan Arm
11
Accessory Attachment
Thread 1/4”-20
1
2
3
4
5
6
7
8
9
10
11
a
9
