The levelling base has a locking knob on one side (a) to lock or unlock the leveller. The friction of the levelling
base is controlled by the D-ring on the underside (b). To adjust the friction of the leveller, simply loosen or
tighten the D-ring.
The Levelling base features a ratchet function in the knob which enables you to reposition the locking knob
if it cannot turn due to its position(c). To adjust the position, pull the ratchet away from the tripod body,
turn it until it has space to move, then click it into place. Then you can turn it to loosen or tighten the lock
as required.
The friction lock/D-Ring (b) can be used to connect either your strap, for carrying, or the bag (d) for ballast,
using the carabiner (e).
The carabiner clip can also be connected to the D-Ring via Toolz (f).
a
Basic Functionality
b
c
d
e
f
b
