360 Systems Image Server 2000 - Page 113

Image Server 2000 Owner’s Manual Page 113
1GPI 1
GPI 1 RTN
9SIGNAL GND
14
10
13GPO 6
25GPO 5
12GPO 4
24GPO 3
11GPO 2
22
INPUTS
OUTPUTS
+5V, 200mA MAX
SOURCE
GPI/O (DB25-F)
1K
INTERNAL CIRCUITS
1K
15
2
3
16
1K
4
17
1K
5
18
1K
6
19
1K
GPO 1 23
GPI 2 RTN
GPI 2
GPI 3 RTN
GPI 3
GPI 4 RTN
GPI 4
GPI 5 RTN
GPI 5
GPI 6 RTN
GPI 6
21
8
Figure 31: GPI Connection Schematic
