Page 114 Image Server 2000 Owner’s Manual
System Board Ports
Standard computer I/O ports on the Image Server include video monitor, keyboard, mouse, and
Gigabit Ethernet ports. Pinouts are provided to assist in wiring or trouble-shooting.
Keyboard and Mouse
Keyboard and mouse ports are provided on the rear panel. Both ports are provided with a
resettable fuse protecting the +5V supply to the peripheral.
SVGA Ports
A VGA or SVGA computer monitor may be connected to the 15-pin video port. The Image
Server is pre-configured to an SVGA screen resolution of 1024 x 768 and 64,000 colors.
The refresh rate will auto-negotiate with the attached monitor to achieve the best available
value. This resolution is best viewed on 17-inch or larger monitors. Use only VESA
compliant monitors. 360 Systems does not provide monitors for the server.
SVGA Connector Pinout
Pin Signal Pin Signal
1 RED 9 +5V
2 GREEN 10 GND
3 BLUE 11 RESERVED*
4 RESERVED* 12 SDA
5 GND 13 HSYNC
6 RED RTN 14 VSYNC
7 GREEN RTN
15 SCL
8 BLUE RTN SHELL FRAME GROUND
* Pulled high to +5V.
Unused Ports
USB ports and an RS-232 serial port are present on the Image Server. These are not active
and no connection should be made to them.
