3Com 4500 - Page 16

16
Tabl e 16 Route Policy View
[4500]route-policy policy 1 permit node 1
Specify name, action and node to see the options below
mdi
Configure the network cable type of the Ethernet ports Port -> Administration
mirrored-to
Enable ACL traffic identification and perform traffic mirror
mirroring-port
Configure a monitored port Port -> Mirroring
monitor-port
Configure a monitor port Port -> Mirroring
multicast-suppression
Configure the multicast traffic size enabled on port
packet-filter
Activate ACL
poe enable*
Enable PoE
poe max-power*
Maximum Power Device -> PoE
poe mode*
Port Mode
poe priority*
Port Priority
port access vlan
Join the access port to a specified VLAN Port -> Administration
port hybrid pvid vlan
Configure the default VLAN ID of the hybrid port Port -> Administration
port hybrid vlan
Join the hybrid port to specified existing VLAN Port -> Administration
port isolate
Add a port to an isolation group Port -> Administration
port link-aggregation
group
Add an Ethernet port into a manual or static aggregation
group
port link-type
Configure the link type of Ethernet port Port -> Administration
port trunk permit vlan
Join trunk port to specified VLAN
port trunk pvid vlan
Configure the default VLAN ID of trunk port
priority
Configure the priority of Ethernet port
priority trust
Configure system trusting the packet 802.1p priority and not
replacing the 802.1p priorities carried by the packets with the
port priority
rmon history
Add an entry to the history control table
rmon statistics
Add an entry to the statistic table
shutdown
Disable the port Port -> Administration
speed
Configure the port speed Port -> Administration
stp
Enable Spanning Tree Protocol Port -> Spanning Tree Per Port
stp cost
Configure the path cost on a spanning tree for the current
Ethernet port
Port -> Spanning Tree Per Port
stp disable
Disable spanning tree protocol on the port
stp edged-port
Configure the current port as an edge port Port -> Spanning Tree Per Port
stp loop-protection
Enable loop protection function Port -> Spanning Tree Per Port
stp mcheck
Force the port to work in RSTP mode Port -> Spanning Tree Per Port
stp point-to-point
Configure the link to the current port as point-to-point link or
not point-to-point link
Port -> Spanning Tree Per Port
stp port priority
Configure the priority of the current Ethernet port Port -> Spanning Tree Per Port
stp root-protection
Enable Root protection Port -> Spanning Tree Per Port
stp transmit-limit
Set the maximum number of STP packets the current port can
send within one Hello time
Port -> Spanning Tree Per Port
unicast-suppression
Configure the limit to unknown unicast flooding
voice vlan enable
Enable the Voice VLAN features on the port
wred
Configure WRED parameters
Command Description Web Command
apply cost
Configure the route cost value of route information
apply tag
Set a tag field of the matched route
Command Description Web Command
