128 CHAPTER 6: IP ROUTING PROTOCOL OPERATION
enabled, then traffic can be distributed equally among interfaces by employing
equivalent routes.
Table 129 Configuring RIP to Filter the Distributed Routes
Displaying and
Debugging RIP
After configuring RIP, enter the display command in any view to display the RIP
configuration, and to verify the effect of the configuration. Enter the
debugging
command in User View to debug the RIP module. Enter the
reset command in RIP
View to reset the system configuration parameters of RIP.
Example: Typical RIP
Configuration
Networking Requirements
As shown in Figure 31, Switch C connects to the subnet 117.102.0.0 through the
Ethernet port. The Ethernet ports of Switch A and Switch B are connected to the
networks 155.10.1.0 and 196.38.165.0 respectively. Switch C, Switch A and
Switch B are connected via Ethernet 110.11.2.0. Correctly configure RIP to ensure
that Switch C, Switch A and Switch B can interconnect.
Configuration Item Command Description
Enter System view system-view
Enter RIP view rip
Enter RIP traffic sharing
among interfaces
traffic-share-across
-interface
Required by default, RIP traffic
sharing among interfaces is
disabled
Table 130 Displaying and Debugging RIP
Operation Command
Display the current RIP running state and
configuration information
display rip
Display RIP inteface information display rip interface
Display RIP routing information display rip routing
Enable the RIP debugging information debugging rip packet
Disable the RIP debugging information undo debugging rip packet
Enable the debugging of RIP receiving packet debugging rip receive
Disable the debugging of RIP receiving packet undo debugging rip receive
Enable the debugging of RIP sending packet debugging rip send
Disable the debugging of RIP sending packet undo debugging rip send
Reset the system configuration parameters of RIP reset
