QoS Configuration 217
Only one monitor port can be configured on one Switch. If a group of Switches
form a Fabric, only one monitor port can be configured on one Fabric.
2 Configure traffic mirroring
Perform the following configuration in the Ethernet Port View.
Tab le 237 Configuring Traffic Mirroring
Delete Traffic Mirroring
1 Delete traffic mirroring
Perform the following configuration in the Ethernet Port View.
Tab le 238 Delete Traffic Mirroring
2 Delete monitor port.
Perform the following configuration in the Ethernet Port View.
Tab le 239 Delete Monitor Port
For details about the command, refer to the Command Manual.
Setting Queue Scheduling
Queue scheduling is commonly used to resolve the problem that multiple
messages compete for resource when the network congestion happens. The
queue scheduling function puts the packet to the output queue of the port
according to the 802.1p priority of the packet. The mapping relationship between
802.1p priority and output queue of the port is as shown in
Tabl e 240.
Tab le 240 Mapping between 802.1p Priority Levels and Outbound Queues
Perform the following configuration in the Ethernet Port View.
Operation Command
Configure traffic mirroring mirrored-to inbound ip-group
acl_number
[
rule
rule
[ link-group
acl_number
rule
rule
]
] | link-group
acl_number
[ rule
rule
] } {
cpu | monitor-interface }
Operation Command
Cancel the
configuration of traffic
mirroring
undo mirrored-to inbound {ip-group {
acl_number
|
acl_name
} [ rule
rule
] | link-group {
acl_number
|
acl_name
} [ rule
rule
] }
Operation Command
Delete monitor port undo monitor
802.1p priority level Queues
0 2
1 0
2 1
3 3
4 4
5 5
6 6
7 7
