350 CHAPTER 12: FILE SYSTEM MANAGEMENT
If user disable NMP Agent, it will be enabled whatever snmp-agent command is
configured thereafter.
Displaying and
Debugging SNMP
After the above configuration, execute the display command in all views to
display the running of the SNMP configuration, and to verify the effect of the
configuration.
Execute the debugging command in User View to debug SNMP
configuration.
Table 429 Display and Debug SNMP
SNMP Configuration
Example
Networking Requirements
Network Management Station and the Switch are connected via the Ethernet. The
IP address of Network Management Station is 129.102.149.23 and that of the
VLAN interface on the Switch is 129.102.0.1. Perform the following
configurations on the Switch: set the community name and access authority,
administrator ID, contact and Switch location, and enable the Switch to send trap
packet.
Operation Command
Display the statistics information about
SNMP packets
display snmp-agent statistics
Display the engine ID of the active device display snmp-agent { local-engineid
| remote-engineid }
Display the group name, the security
mode, the states for all types of views,
and the storage mode of each group of
the Switch.
display snmp-agent group [
group-name
]
Display the names of all users in the group
user table
display snmp-agent usm-user [
engineid
engineid
] [ group
groupname
] [ username
username
]
Display the current community name display snmp-agent community [ read
| write ]
Display the current MIB view display snmp-agent mib-view [
exclude | include | viewname
mib-view
]
Display the contact character string of the
system
display snmp-agent sys-info contact
Display the location character string of the
system
display snmp-agent sys-info
location
Display the version character string of the
system
display snmp-agent sys-info version
