12. SLIDE LOADER 3D
SERVICE GUIDE
45
12. The minimal lengths, which each unit must be able to travel, are pre-defined in micrometer in the software. If the resulted travel length is over
the pre-defined range, it normally refers to a service/measurement fault. In case of a fault, the actual row is signed with red under Relative
hardware limits.
Hardware limits
Calculated full travel
length
Acceptance range
