Kit No. Insulation Diameter Range 25kV (AWG/kcmil)
100% 133%
(260 mils) (320 mils)
Inches (mm) Stranded Compact/Solid Stranded Compact/Solid
5811-B* 0.700–0.910 2 2–1
5811-B-3 (17.8–23.1) 2
5811-B-2 2 1
5811-C* 1–3/0 1/0–4/0 2–1/0 2–1/0
5811-C-3 2
5811-C-2 0.850–1.100 2 1
5811-C-1 (21.6–27.9) 1 1/0 1 1/0
5811-C-1/0 1/0 2/0 1/0
5811-C-2/0 2/0 3/0
5811-C-3/0 3/0 4/0
5811-D* 4/0–250 250 2/0–4/0 2/0–4/0
5811-D-1/0 2/0
5811-D-2/0 1.040–1.250 2/0 3/0
5811-D-3/0 (26.4–31.8) 3/0 4/0
5811-D-4/0 4/0 250 4/0
5811-D-250 250
*Kit without compression connector.
Table 1. Kit Selection Table for 25 kV Class
