Model C1060 Headset Intercom System Replacement Parts and Service
©3M 2005 November 5
Item No. Part Number Description Qty.
0 .......................78-6911-4723-1 ............Headset Model C1060 .............................................................1
1 .......................78-6911-4727-2 ............Headband Pad, for Model C1060 (pkg of 10)..........................1
2 .......................78-6911-4728-0 ............Ear Pad, for Model C1060 (pkg of 10)....................................1
3 .......................78-6911-4729-8 ............Ear Cup, for Model C1060 (pkg of 5) .....................................1
4 .......................78-8117-4110-3 ............Safety Strap..............................................................................1
5 .......................N/A separately ..............Screw, 2-56 X .4375 Pan Hd. Phillips, Stainless, Black..........5
6 .......................78-8117-4088-1 ............Clip, Headband Slide (min. order qty. 20)...............................1
7 .......................78-8117-4123-6 ............Headband Assembly (includes Clip, Headband Slide)............1
8 * ...................N/A separately ..............PWA, Battery Holder...............................................................1
9 * ...................N/A separately ..............Base, Battery Holder................................................................1
10* ...................N/A separately ..............Cover, Battery Holder..............................................................1
11*/ ** .............N/A separately ..............Button, Battery Latch...............................................................1
12*/ ** .............N/A separately ..............Latch, Battery ..........................................................................1
13*/ ** .............N/A separately ..............Spring, Battery Latch...............................................................1
14 .....................N/A ...............................Mic, Boom...............................................................................1
14A...................N/A ...............................Washer, Nylon, Mic Boom......................................................1
14B...................N/A ..............................Washer, Spring, Mic Boom .....................................................1
14C...................N/A ...............................Retaining Ring, Mic Boom......................................................1
14D...................78-6911-4745-4 ............Windscreen Mic (pkg of 10)....................................................1
15 .....................78-8117-4133-5 ............Outer Case Assembly (contains LED Lens, Bezel, Switches).1
16 .....................N/A separately ..............Lens, LED (contained in Outer Case Ass’y (item 15))............1
17 .....................78-8117-4127-7 ............Inner Case Assembly (contains IR Lens, Speaker, 3 Screws).1
18 .....................N/A separately ..............Lens, IR (contained in Inner Case Ass’y (item 17))................1
19 .....................78-6911-4721-5 ............Battery Model C1060 ..............................................................1
20 .....................N/A ...............................PWA, Main, Model C1060......................................................1
* These parts are contained in Battery Terminal Kit, 78-6911-4160-8 including two Screws (item 5) and one
Headband Pad (item 1)
**These parts are contained in Battery Latch and Button Kit, 78-6911-4910-4
