3M PELTOR EEP-100 EU User Manual

4
A:1
A:2
A:3
A:4
A:5
Fig. A
Product Note
• Storage temperature (complete kit): -20°C to 50°C (-4°F to 122°F )
• Operating temperature earpiece: -20°C to +50°C (-4°F to 122°F)
• Operating temperature charger: 0°C to +45°C (32°F to 113°F)
Product Components: Earpiece
1. Power/Control button (Silicone TPV)
(Fig. A:1)
2. Microphone (ABS plastic) (Fig. A:2)
3. Charging contacts (Gold) (Fig. A:3)
4. Eartip stem (ABS plastic) (Fig. A:4)
5. Eartip (SEBS TPE, Urethane foam)
(Fig. A:5)
B:2
B:1
Fig. B
B:7
B:3
B:4
B:5 B:6
Fig. C
C:2
C:1
C:4
C:2
C:3
Charging Case: TEP-200 EU/
LEP-200 EU/LEP-200 EU OR
1. Battery compartment (Fig. B:1)
2. Retention cord storage posts (Fig. B:2)
3. Test/Status button (Fig. B:3)
4. Earpiece charging receptacle (Fig. B:4)
5. Indicator light (Fig. B:5)
6. Micro B USB charging port (Fig. B:6)
7. Latch (Fig. B:7)
Charging Case:
EEP-100 EU/EEP-100 EU OR
1. Earpiece charging receptacle (Fig. C:1)
2. Indicator light (Fig. C:2)
3. Micro B USB charging port (Fig. C:3)
4. Latch (Fig. C:4)
Charging
The 3M™ PELTOR™ TEP-200 EU/
LEP-200 EU/LEP-200 EU OR and EEP-
100 EU/EEP-100 EU OR Earplugs should
be charged before use.
Note: To maximize battery life, always
store earbuds in the case.
• For the
TEP-200 EU/LEP-200 EU/
LEP-200 EU OR
, the earpieces are
charged inside the charging case
using 3 AA batteries or Micro B USB
cord (not provided). Charging time is
approximately 90 minutes, regardless of
charging method.
• For the EEP-100 EU/EEP-100 EU OR,
the earpieces are charged using a Micro
B USB cord (provided). Charging time is
approximately 180 minutes.
EN

3M PELTOR EEP-100 EU Specifications

General

Category	Accessories
Model	EEP-100 EU
Brand	3M PELTOR
Type	Electronic Earplug
Battery Type	Rechargeable Lithium-Ion
Quantity per Package	1 pair
Certification	CE
Operating Time	16 hours
Standards Met	EN 352-2
Material	Plastic
Color	Black
